Zmorph VX User Manual

3D printing workow
70
DUAL PRO Extruder
Connect the LEFT cable
to the LEFT frame socket
and RIGHT cable to the
RIGHT frame socket
Connect the extruder "A"
cable to the "A" plug and
the 'B' cable to the "B"
plug on the X carriage.
Choose "Maintenance".
NOTE: Before performing the automatic calibration make sure the worktable is clean
and prepared.
NOTE: See the toolhead changing process before mounting the Dual PRO extruder on
the machine.
NOTE: During the automatic calibration process the printer is heating up!
Choose "Calibrate". Choose "Auto 3-point".
Wait for the machine to
heat up and nish the
probing.
To ensure best calibra-
tion result print calibra-
tion pattern. Choose
"Start".
Set the printing tempera-
ture to the PLA material.,
Nozzle 200 °C, bed 60 °C.
To to that tap the gaps
and type the temperature
on the keyboard.
Wait for extruder to
heat up. When done tap
"NEXT".
