Zoom F3 User Manual

Specifications
Inputs MIC/LINE (mono) 2
LINE OUT 1
Input and output
channels
Outputs
PHONE OUT 1
Connectors 2 XLR (2: HOT)
Input gain Adjustment unnecessary (dual AD
converter circuits used)
Input impedance MIC: 3 kΩ or more
LINE: 3 kΩ or more
Maximum input level MIC: +4 dBu
LINE: +24 dBu
Phantom power +24/48 V
Combined channel total of 10 mA or
less
Inputs MIC/LINE (mono)
Equivalent input noise −127 dBu or less (IHF-A) when
waveform magnification is ×1024 with
150 Ω input
Connector 1 stereo mini jack
Maximum output level +1 dBu
LINE OUT
Output impedance 100 Ω or less
Connector 1 stereo mini jack
Maximum output level 50 mW + 50 mW (into 32 Ω load)
Outputs
PHONE OUT
Output impedance 15 Ω or less
Maximum simultaneous
recording tracks
2
Maximum simultaneous
playback tracks
2
Recording format WAV
44.1/48/ 88.2/96/192 kHz,
32-bit float mono/stereo
BWF and iXML formats supported
Recorder
Recording media 4 – 32 GB cards compatible with the
microSDHC specification
64 GB – 1 TB cards compatible with
the microSDXC specification
Display LCD with backlight (96×64 resolution)
103

Zoom F3 Specifications

General

XLR in	Yes
Audio (L/R) out	1
Sample rate	192 kHz
Audio quality	32 bit
Product color	Gray

Weight and Dimensions

Weight	242 g
Dimensions (WxDxH)	75 x 77.3 x 47.8 mm
