Changing phantom power voltage
The phantom power voltage can be changed by selecting +24V or +48V.
The selected voltage setting will be applied to both Input 1 and Input 2.
1. Press for Input 1 or Input 2. (→ Selecting inputs for making settings)
This opens the Input Settings Screen.
2. Use / to select “Phantom Volt.” and press to confirm.
3. Use / to select the voltage and press to confirm.
HINT:
• Phantom power is a function that supplies power to equipment that uses an external power supply,
including some condenser mics. The standard power is +48V, but some equipment can operate with
lower voltages.
• By setting the phantom power voltage to +24V when using mics that can operate on this voltage,
continuous battery operation time can be lengthened.
35
