Adjusting line output levels (playing test tones)
The line output levels to connected equipment can be adjusted.
Test tones can be played in order to adjust the levels for a digital SLR camera or other equipment.
1. Minimize the input gain of the other equipment.
2. Use an audio cable to connect the external mic jack of the other equipment with the F3 LINE OUT jack.
NOTE:
When output to a digital SLR camera or other equipment is not necessary, do not connect anything to the
LINE OUT jack.
When nothing is connected to the LINE OUT jack, the line output function is automatically disabled, which
could lengthen continuous battery operation time.
3. Use / to select “Output” and press to confirm.
4. Use / to select “Line Out Level” and press to confirm.
To output a test tone from the F3 to adjust the output level, skip to step 6.
5. Use / to adjust the line output level and press to confirm.
41
