Specifications
Inputs MIC/LINE (mono) 2
MASTER OUT 1
Input and output
channel counts
Outputs
PHONES 1
Connectors 2 XLR/TRS combo jacks
(Balanced, XLR: 2 HOT / TRS: TIP
HOT）
Input gain +6 dB – +50 dB
Input impedance XLR: 3.9 kΩ
TRS: 3.9 kΩ/1 MΩ (when Hi-Z ON,
INPUT 1 only)
Phantom power +48 V (switchable separately for
INPUTS 1 and 2)
Equivalent input noise –121 dBu or less (IHF-A) at +50 dB/150
Ω input
Inputs
Frequency response −1.0/+0.5 dB: 20 Hz – 20 kHz
Connectors 2 TRS phone jacks (balanced)
Maximum output level +14 dBu
MASTER OUT
Output impedance 200 Ω
Connectors 1 stereo 3.5mm mini jack
Maximum output level 45 mW + 45 mW (into 32 Ω load)
Outputs
PHONES
Output impedance 10 Ω
Maximum simultaneous
recording tracks
2
Maximum simultaneous
playback tracks
8
Recording format 44.1 kHz, 16/24-bit, mono/stereo WAV
Recorder
Recording media Cards compatible with microSDHC
specifications
4 GB – 32 GB
Cards compatible with microSDXC
specifications
64 GB – 1 TB
EQ High: 10 kHz, ±12 dB, shelving
Middle: 2.5 kHz, ±12 dB, peaking
Low: 100 Hz, ±12 dB, shelving
Track settings
Pan L100 – R100
Effects Input Dynamics Comp/Limiter/Gate
193
