Setting up
11
4 Setting up
4.1 Overview
Cutter with optional light curtain without material
transport
with material
transport
without CE Yes No
1/2 CE front — No
1/2 CE rear — No
1/2 CE front + 1/2 CE rear — No
1/1 CE front — No
1/1 CE rear — No
1/1 CE front + 1/1 CE rear — Yes
1/2 CE = cutter extension half cutter length
1/1 CE = cutter extension entire cutter length
Warning:
The cutter with the 120 mm clearance may only be operated with a light curtain.
For the cutter with the 60 mm clearance a light curtain is optional.
Tip:
The rear access guard and the S-Box are already mounted on the cutter with 120 mm clearance.
The cutter with the 60 mm clearance can be retrofitted for the light curtain.
4.2 Turn off the cutter.
Switch off the cutter at the main switch and secure against unintentional restart.
