Zünd G3 - Fastening the Pillars to the Floor (with Segment Anchors)

Cutter without material transport
39
7.2 Fastening the pillars to the floor (with segment anchors)
Caution:
Incorrect set-up of the pillars can lead to accidents
The distances of the pillars to the cutter must be strictly observed.
• Check the positions of the marked drill holes using the reference dimension (see imprint on the
drilling templates orDiagrams on page 99).
Note:
For cutters2XL-3200and3XL-3200only pillars with light barrier transmitters/receivers are used due
to the large distances.
Pillar with mirror Pillar with light barrier transmitter/receiver
