Setting up the light curtain
73
10 Setting up the light curtain
10.1 Aligning the pillars vertically
1 Nut (3 x)
Note:
Observe prescribed tightening of the nuts.
• The thread must overhang at least 8 mm.
• The springs may not be completely compressed.
A Use the spirit level on two sides to check whether the pillar is vertical.
B Loosen or tighten the corresponding nuts until the pillar is vertical.
C Repeat the process on the other corners.
