Zünd G3 - Mounting the Pillars Onto the Auxiliary Brackets

Cutter with material transport and CE
63
8.4 Mounting the pillars onto the auxiliary brackets
8.4.1 Placing the base frame on consoles
Caution:
Risk of crushing - high cutter weight.
• Do not reach beneath the raised base.
• Use a tool to remove the leveling pad.
Tip:
A second person is needed for lifting to place the supports and position the auxiliary brackets.
