Zünd G3 - Diagrams; Overview

Diagrams
99
14 Diagrams
14.1 Overview
Reference dimension – drilling pattern for the light curtain pillars
Identification Name Version
5210682 Assembly base reference dimension -
5210816 Assembly base reference dimension material transport -
5210674 Assembly base reference dimension material transport
2XL-3200/3XL-3200
-
5217535 G3 foam cutter safety device complete light curtain 2S/2E,
material t. Bhs150
-
5217309 G3 foam cutter safety device complete light curtain 3S/3E,
material t. Bhs150
-
Electrical system/electronics
Identification Name Version
5210885 wiring SLC left, rear, right, front with 4 RXs/4 TXs V1_0_B
5210886 wiring SLC 2 RXs/2TXs with mirrors V1_0_B
5210866 wiring SLC left and right V1_0_A
