Zünd G3 - Laying and Connecting Cables

Connecting the light barrier transmitter and receiver
70
9.1 Laying and connecting cables
Figure 2: Labeling on the yellow light grid (type 445L)
1 Labeling on the transmitter 3 Labeling on the receiver
2 Cable from the S-box
Figure 3: Labeling on the red light grid (type 450L-E)
1 Transmitter connection cable (T) 3 Receiver connection cable (R)
2 Cable from the S-box
