Cutter without material transport
40
7.2.1 Cutter without material transport
Two drilling templates are included in the scope of delivery. These are used to mark the drill holes on
the base of the cutter.
The number and labeling indicate the cutter size and side to which the drilling template applies.
Labeling Cutter Position
5209090 G3 M, L, XL Front left and rear right
5209097 G3 M, L, XL Front right and rear left
5209090 G3 2XL-3200, 3XL-3200 Front left and rear right
5210613 G3 2XL-3200, 3XL-3200 Front right and rear left
Example of a drilling template
1 Drill holes for front right
2 Drill holes for rear left
Reference dimension on the drilling template
