Chapter 49 OSPF Commands

Ethernet Switch CLI Reference Guide

210

This example shows you how to enable the redistribution for RIP protocol and then show all

redistribution entries.

From the example above, the third octet of all the four network IP addresses is 00001000,

00001001, 00001010, 000001011 respectively. The first 4 digits (000010) are the common

part among these IP addresses. So 192.168.8.0/22 can be used to represent all of the 4

networks. The following example shows you how to configure the OSPF summary address

and then show all redistribution entries.

sysname# config

sysname(config)# router ospf 172.16.1.1

sysname(config-ospf)# redistribute rip metric-type 1 metric 123

sysname(config-ospf)# exit

sysname(config)# exit

sysname# show ip ospf database

OSPF Router with ID (172.16.1.1)

(Omit not external part °K)

AS External Link States

Link ID ADV Router Age Seq# CkSum Route

192.168.8.0 192.168.2.2 618 0x80000001 0x02f6 E1 192.168.8.0/24

192.168.9.0 192.168.2.2 618 0x80000001 0xf601 E1 192.168.9.0/24

192.168.10.0 192.168.2.2 618 0x80000001 0xeb0b E1 192.168.10.0/24

192.168.11.0 192.168.2.2 618 0x80000001 0xe015 E1 192.168.11.0/24

sysname# config

sysname(config)# router ospf 172.16.1.1

sysname(config-ospf)# summary-address 192.168.8.0 255.255.252.0
