Chapter 57 Private VLAN Commands
Ethernet Switch CLI Reference Guide
235
This example sets a private VLAN rule (pvlan-111) that applies to VLAN 111. Ports 1, 2 and
24 belong to VLAN 111. Ports 1 and 2 are added to the isolated port list automatically and
cannot communicate with each other. Port 24 is the uplink port and also the promiscuour port
in this VLAN. The isolated ports in VLAN 111 can send and receive traffic from the uplink
port 24. This example also shows all private VLAN rules configured on the
Switch.
sysname# configure
sysname(config)# private-vlan name pvlan-111 vlan 111
sysname(config)# exit
sysname# show private-vlan
Private VLAN: 111 Active: Yes
Name Promiscuous Port
------------ --------------------------
pvlan-111 24
sysname#
