Chapter 85 Additional Commands
Ethernet Switch CLI Reference Guide
327
This example displays run-time SFP (Small Form Facter Pluggable) parameters on ports 9 (the
first SFP port 0, with an SFP transceiver installed) and 10 (the second SFP port 1, no SFP
transceiver installed) on the
Switch. You can also see the alarm and warning threasholds for
temperature, voltage, transmission bias, transmission and receiving power as shown.
This example displays run-time SFP (Small Form Facter Pluggable) parameters on port 21 on
the
Switch. You can also see the alarm and warning threasholds for temperature, voltage,
transmission bias, transmission and receiving power as shown.
This example displays the firmware version the Switch is currently using..
sysname# show sfp 9-10
SFP : 0
Part Number : SFP-SX-DDM
Series Number : S081113001132
Revision : V1.0
Transceiver : 1000BASE-SX
Temperature(C) Alarm(80.00 ~ 0.00), Warning(75.00 ~ 5.00), Current(38.00)
Voltage(V) Alarm(3.50 ~ 3.10), Warning(3.45 ~ 3.15), Current(3.37)
Tx Bias(mA) Alarm(100.05 ~ 1.00), Warning(90.04 ~ 2.00), Current(5.25)
Tx Power(dBm) Alarm(-2.99 ~ -8.98), Warning(-3.49 ~ -8.48), Current(-6.05)
Rx Power(dBm) Alarm(-2.99 ~ -18.01), Warning(-3.49 ~ -17.39), Current(-4.24)
SFP : 1
Not Available
sysname# show interface transceiver 21
Transceiver Information
Port : 21 (SFP)
Vendor : ZyXEL
Part Number : SFP-LX-10-D
Series Number : S081133000074
Revision : V1.0
Date Code : 2008-08-11
Transceiver : 1000BASE-LX
++ : high alarm, + : high warn, - : low warn, -- : low alarm.
Current High ALarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
-------------- ----------- ------------ ----------- ----------- -----------
Temperature(C) ++ 38.00 -1.00 75.00 5.00 0.00
Voltage(V) 3.36 3.50 3.45 3.15 3.10
Tx Bias(mA) 14.53 100.05 90.04 7.00 6.00
Tx Power(dBm) -5.80 -2.99 -3.49 -8.96 -9.50
Rx Power(dBm) + -3.36 -2.99 -3.49 -20.50 -21.02
sysname#
sysname# show version
Current ZyNOS version: V3.80(BBA.3)b1 | 04/17/2008
