Chapter 40 Diagnostics
ZyWALL ATP Series User’s Guide
788
40.7 The Network Tool Screen
Use this screen to perform various network tests.
Click Maintenance > Diagnostics > Network Tool to display this screen.
Figure 546 Maintenance > Diagnostics > Network Tool
Password Type a password for the selected user/group to allow external access.
SSH Port This field displays the SSH port number for external access. It should be the same port
number as the one configured in Configuration > System > SSH.
HTTPS Port This field displays the HTTPS port number for external access. It should be the same port
number as the one configured in Configuration > System > WWW > Service Control.
IP Address1 Enter the public IP address of the external user that is allowed to access the Zyxel Device
remotely.
IP Address2 Enter the public IP address of the external user that is allowed to access the Zyxel Device
remotely.
Schedule
Name This field displays the name of the schedule for allowed external access. The schedule
must be first configured in Object > Schedule.
Start Date This field displays the date on which the schedule begins.
Start Time This field displays the time at which the schedule begins.
Stop Date This field displays the date on which the schedule ends.
Stop Time This field displays the time at which the schedule ends.
Apply Click Apply to save your changes back to the Zyxel Device.
Reset Click Reset to return the screen to its last-saved settings.
Table 351 Maintenance > Diagnostics > Remote Assistance (continued)
LABEL DESCRIPTION
