144 | Aprisa LTE User Manual
Rule is Enabled
Toggles the rule ON or OFF. If unchecked, the rule will not be deleted, but it also will not be loaded into
the firewall.
Name
Name of the rule, used purely for easier management purposes.
Protocol
Type of protocol of incoming packet
Source zone
Packets arriving from the specified source zone will match this rule. The special ‘device’ zone matches
packets that originate from the Aprisa LTE. Any Zone may also be specified. Default value is wan: ppp
Source Address
The source zone from which data packets will redirected from.
Destination Address / Port
Redirect matched traffic to the given IP address and destination port.
Action
Action to be performed with the packet if it matches the rule.
