Aprisa LTE User Manual 2.1
Antennas
The following antennas are available from 4RF as accessories:
Aprisa LTE cellular multiband antenna GNSS x1 / LTE x2 / WiFi x2
Dimensions - (LxWxH) 202.3mm x 88.5mm x 45mm (7.96 in x 3.48 in x
1.77 in)
Mount - Direct Mount
Connectors - 5x QMA straight
Cables - 5.2m black
WiFi / LTE cable LMR-195
GNSS cable LMR-100
Aprisa LTE omnidirectional low PIM collinear antenna operates over
the CBRS band 3550-3700 MHz
Dimensions – diameter x height – mm (inches) 25.4 x 257 (1.0 x 10.0)
Polarization - Vertical, Linear
Connectors - N type Female
Gain - 6.8 dBi
Aprisa LTE 3.3-4.01 GHz dual polarization / dual slant panel antenna
Dimensions – 305 x 305 x 25 mm
Polarization - Dual Linear
Vertical Beamwidth - 17deg
Horizontal Beamwidth - 17deg
Connectors - 2x N type Female
Gain - 19.5dBi
