Monitoring > VPN
This page displays the router VPN performance monitoring parameters.
This shows a list of active IPSec connections. Each entry in the Connections list corresponds to an IPSec
connection configuration entry.
Name
This is the Connection Name configuration for this connection.
Version
The IKE version of the connection (either IKEv1 or IKEv2)
Local
The local address used for the connection
Remote
The remote address used for the connection
Status
The status (CONNECTING or ESTABLISHED)
Reauth In
The remaining time till a re-authentication will be performed
Age
The time since the previous re-authentication
Each entry in the Child Connections list shows an IPSec Tunnel configuration that is active.
ID
ID for this tunnel
Name
The configured Tunnel Name for the IPSec tunnel
Connection
The configured Connection Name for the IPSec connection that this tunnel is using
Local
The local subnet in packets sent over this tunnel
Remote
The remote subnet in packets sent over this tunnel
Status
The status of this tunnel
In/Out Byte
The total number of bytes received/sent on this tunnel
In/Out Pkts
The total number of packets received/sent on this tunnel
Last In/Out
The time since last input/output packet was received/sent
Type
The type of this tunnel. Either Tunnel or Transport
