Interfaces
Antenna Interfaces
LTE Front
• MAIN - Main cellular QMA 50 ohm female connector
• GNSS - Global Navigation Satellite System QMA 50 ohm female connector
• DIVERSITY – Diversity Cellular QMA 50 ohm female connector
• Wi-Fi 1 and Wi-Fi 2 antenna QMA 50 ohm female connectors
LTE Rear
• Dual SIM socket – a dual socket for fitting 2 x micro SIM cards
Ethernet Interface
• 2 port 10/100/1000 base-T Ethernet layer 2 switch using RJ45 female connector
Used for Ethernet user traffic and modem network management.
RS-232 / RS-422 / RS-485 Interface
• 1 port RS-232 / RS-422 / RS-485 asynchronous port using RJ45 female connector
USB Interface
• 1 x USB port using USB standard type C female connector
Used for software upgrade, diagnostic reporting and configuration save / restore.
SFP Module Socket
• 1 x SFP Module Socket for fitting of optional SFP modules see ‘SFP Modules’ on page 41
