Cables
The following cables are available from 4RF as accessories:
Part Number
Description
APLB-PPWR-X01
Aprisa LTE power cable fitted with 4 pin Molex Micro-Fit 3.0 female
connector and wire ended
Cable length 1m
Pin 1 Red +ve Power Input
Pin 2 Black -ve Power Input
Pin 3 Green Digital Input
Pin 4 White Digital Output
APLB-PPWR-X10
Aprisa LTE power cable fitted with 4 pin Molex Micro-Fit 3.0 female
connector and wire ended
Cable length 10m
Pin 1 Red +ve Power Input
Pin 2 Black -ve Power Input
Pin 3 Green Digital Input
Pin 4 White Digital Output
