Interface Specifications
Ethernet Interface
The Aprisa LTE router features two integrated IEEE 802.3 Ethernet 1000Base-TX interfaces.
To simplify network setup, each port supports auto-negotiation and auto-sensing MDI/MDIX. Operators can
select from the following preset modes:
• Auto negotiate
The Ethernet ports are IEEE 802.3-compatible. The L2 Bridge (Switch) is IEEE 802.1d/q/p compatible,
supporting VLANs and VLAN manipulation of add/remove VLANs.
General
Interface
RJ45 x 2 (Integrated 2-port switch)
Cabling
CAT-5/5e/6 UTP/STP, supports auto MDIX (Standard
Ethernet)
Maximum line length
100 metres on cat-5 or better
Bandwidth allocation
The Ethernet capacity maximum is determined by the
available LTE router link capacity.
Maximum transmission unit
Option setting up to 9216 bytes (Jumbo packet)
Address table size
Unlimited
Ethernet mode
10Base-T, 100Base-TX, 1000Base-TX
Full duplex or half duplex
(Auto-negotiating and auto-sensing)
Diagnostics
Left Green LED
Off: no Ethernet signal received
On: Ethernet signal received
Right Orange LED
Off: no data present on the interface
Flashing: data present on the interface
Note: Do not connect Power over Ethernet (PoE) connections to the Aprisa LTE Ethernet ports as this will
damage the port.
Ethernet Interface (with SFP)
The Aprisa LTE router has one SFP Module Socket for fitting of optional SFP modules see ‘SFP Modules’ on
page 41. An Ethernet SFP module can be fitted in this socket.
Operators can select from the following preset modes:
• Auto negotiate
The SFP Ethernet port is IEEE 802.3-compatible. The L2 Bridge (Switch) is IEEE 802.1d/q/p compatible,
supporting VLANs and VLAN manipulation of add/remove VLANs.
