4RF Aprisa LTE - Earthing; LTE Earthing

LTE Router Installation | 53
Aprisa LTE User Manual 2.1
Earthing
LTE Earthing
The Aprisa LTE has an earth connection point on the top left of the enclosure. A M4 8mm pan pozi machine
screw and M4 lock washer is supplied fitted to the router. This screw is used to earth the enclosure to a
protection earth. A minimum of 0.8 mm
2
(18 AWG) wire shall be used and it shall not contain switches or
protective devices.
