4RF Aprisa LTE - Power Specifications; Power Supply; General Specifications; Environmental

246 | Aprisa LTE User Manual
Power Specifications
Power Supply
Input voltage
+9 to +32 VDC negative earthed
Sleep power
< 40 mW
Idle power
< 3.5 W
Peak power
< 15 W
Connector
Pins 1 & 2 of Molex Micro-Fit 3.0 Male
Connector
General Specifications
Environmental
Operating temperature range
-30 to +70˚ C (-22 to +158˚ F)
Storage temperature range
-40 to +85˚ C (-40 to +185˚ F)
Max thermal loading
26.6 BTU/hr
Operating humidity
Maximum 95% non-condensing
Acoustic noise emission
No audible noise emission
Mechanical
Dimensions
Width 177 mm (6.97”)
Depth 110 mm (4.33”) and 136 mm (5.35”)
with QMA connectors
Height 41.5 mm (1.63”)
Weight
740 g (1.67 lbs)
Colour
Matt black
Mounting
Wall (2 x M5 screws)
Rack shelf (4 x M4 screws)
DIN rail bracket
