Managing the LTE | 171
Aprisa LTE User Manual 2.1
VPN > IPSec Tunnel
This page provides VPN IPSec Tunnel configuration.
IPSec tunnels define what networks are connected at each end of the link. The actual connection to the
remote end-point used for a given tunnel is configured separately in the IPSec connection tab (this is because
multiple tunnels may use the same connection).
Tunnel Name
Name of this tunnel
Mode
Option
Function
Tunnel
This encapsulates the IP header and the payload and introduces a
new outer header. Can be used to create site-site VPNs
Transport
This encapsulates only the IP payload, and not the header. It
provides a secure connection between two endpoints.
Often combined with other tunneling protocol (e.g. GRE) to create
site-site VPNs
Local Subnet
An IPv4 or IPv6 address/prefix. Packets with source address matching this will be sent on the tunnel
Remote Subnet
An IPv4 or IPv6 address/prefix. Packets with destination address matching this will be sent on the tunnel
