System Functions and Features as of I7.9
Features 489
syd-0200/3.0 – I7.9 – 11.2009
8. 9. 2 Room-to-room traffic
If room-to-room traffic is enabled, guests have the possibility of telephoning di-
rectly to other rooms.
Traffic between rooms/phone booths can be configured with the following meas-
ures:
General configuration as the basic setup for all rooms.
Specific configuration per room port for room status Occupied.
If the room status is Free, the system automatically resets the default values.
The room-to-room traffic configuration can be modified by the System Assistant on
Office 45, e.g. to allocate special privileges to travel groups.
Secret code
The secret code feature (*34) allows barred room-to-room traffic and internal digit
barring to be bypassed. If *34 is barred in the internal digit barring, "secret code"
cannot be activated. The room-to-room configuration applies exclusively.
The secret code allows key hotel management staff for example to make calls to
otherwise barred users. If the secret code is disclosed to a group of guests, room-
to-room traffic can also be enabled.
Note: This feature is not described in any of the operating instructions.
