ABB ACQ580 Firmware Manual

List of related manuals
You can find manuals and other product documents in PDF format on the Internet. See section Document
library on the Internet on the inside of the back cover. For manuals not available in the Document library,
contact your local ABB representative.
Drive manuals and guides Code (English)
ACQ580 pump control program firmware manual
3AXD50000035867
ACQ580-01 (0.75 to 250 kW, 1.0 to 350 hp) hardware
manual
3AXD50000035866
ACQ580-01 quick installation and start-up guide for
frames R0 to R5
3AXD50000035755
ACQ580-01 quick installation and start-up guide for
frames R6 to R9
3AXD50000037301
ACX-AP-x assistant control panels user’s manual 3AUA0000085685
Option manuals and guides
CDPI-01 communication adapter module user's manual
3AXD50000009929
DPMP-01 mounting platform for control panels 3AUA0000100140
DPMP-02/03 mounting platform for control panels 3AUA0000136205
FDNA-01 DeviceNet™ adapter module user's manual 3AFE68573360
FENA-01/-11/-21 Ethernet adapter module user's
manual
3AUA0000093568
FPBA-01 PROFIBUS DP adapter module user's manual
3AFE68573271
FSCA-01 RS-485 adapter module user's manual 3AUA0000109533
Flange mounting kit installation supplement
3AXD50000019100
Flange mounting kit quick installation guide for
ACX580-01 frames R0 to R5
3AXD50000036610
Flange mounting kit quick installation guide for
ACS880-01 and ACX580-01 frames R6 to R9
3AXD50000019099
Tool and maintenance manuals and guides
Drive composer PC tool user's manual 3AUA0000094606
Converter module capacitor reforming instructions
3BFE64059629
NETA-21 remote monitoring tool user's manual 3AUA00000969391
NETA-21 remote monitoring tool installation and start-up
guide
3AUA0000096881
ACQ580-01 manuals

ABB ACQ580 Specifications

General

Protection class	IP21, IP55
Ambient temperature range	-15°C to +50°C
Communication protocols	Modbus RTU
Mounting type	Wall mounted
Control method	vector control
Frequency range	0 Hz to 500 Hz
Protection features	Overcurrent, overvoltage, undervoltage, short circuit
