ABB ACQ580 Firmware Manual

Parameters 277
82.37 Outlet maximum
pressure warning
level
Defines the level at which drive should generate the outlet
maximum pressure warning.
0.00
0.00...32767.00 bar Outlet maximum pressure warning level. 1 = 1 bar
82.38 Outlet maximum
pressure fault level
Defines the level at which drive should generate the outlet
maximum pressure fault.
0.00
0.00...32767.00 bar Outlet maximum pressure fault level. 1 = 1 bar
82.40 Inlet minimum
pressure protection
Enables inlet minimum pressure protection function. Disabled
Disabled Inlet minimum pressure protection is disabled. 0
Warning Inlet minimum pressure protection function generates D510
Inlet minimum pressure warning when the pressure is below
the level defined with parameter 82.41 Inlet minimum
pressure warning level for a time set in 82.45 Pressure check
delay.
1
Fault Inlet minimum pressure protection function generates D40A
Inlet minimum pressure fault when the pressure is below the
level defined with parameter 82.42 Inlet minimum pressure
fault level for a time set in 82.45 Pressure check delay.
2
Warning/Fault Inlet minimum pressure protection function first generates a
warning when the pressure is below the level defined with
parameter 82.41 Inlet minimum pressure warning level for a
time set in 82.45 Pressure check delay.
If the pressure continues to fall below the level defined with
parameter 82.42 Inlet minimum pressure fault level, a fault is
generated.
3
82.41 Inlet minimum
pressure warning
level
Defines the level at which drive should generate the inlet
minimum pressure warning.
0.00
0.00...32767.00 bar Inlet minimum pressure warning level. 1 = 1 bar
82.42 Inlet minimum
pressure fault level
Defines the level at which drive should generate the inlet
minimum pressure fault.
0.00
0.00...32767.00 bar Inlet minimum pressure fault level. 1 = 1 bar
82.45 Pressure check
delay
Defines the delay time at which the pressure supervisions are
inactive.
You can adjust check delay for a system in which the
pressure does not increase immediately after starting the
motor.
3.00
0.00...3600.00 s Pressure check delay time. 1 = 1 s
83
83 Pump cleaning
Settings for the pump cleaning sequence.
See section Pump cleaning (page 54).
83.01 Pump cleaning
status
Displays the status of pump cleaning. Disabled
Disabled Cleaning sequence is disabled. 0
Pump clean Cleaning sequence is active. 1
No triggers
configured
Triggers are not configured. 2
Waiting for
triggering
Waiting for triggering signal. 3
No. Name/Value Description Def/FbEq16

ABB ACQ580 Specifications

General

Protection class	IP21, IP55
Ambient temperature range	-15°C to +50°C
Communication protocols	Modbus RTU
Mounting type	Wall mounted
Control method	vector control
Frequency range	0 Hz to 500 Hz
Protection features	Overcurrent, overvoltage, undervoltage, short circuit
