Additional parameter data 301
7
Additional parameter data
What this chapter contains
This chapter lists the parameters with some additional data such as their ranges and
32-bit fieldbus scaling. For parameter descriptions, see chapter Parameters (page
99).
Terms and abbreviations
Term Definition
Actual signal Signal measured or calculated by the drive. Usually can only be monitored
but not adjusted; some counter-type signals can however be reset.
Analog src Analog source: the parameter can be set to the value of another parameter
by choosing “Other”, and selecting the source parameter from a list.
In addition to the “Other” selection, the parameter may offer other pre-
selected settings.
Binary src Binary source: the value of the parameter can be taken from a specific bit
in another parameter value (“Other”). Sometimes the value can be fixed to
0 (false) or 1 (true). In addition, the parameter may offer other pre-selected
settings.
Data Data parameter
FbEq32 32-bit fieldbus equivalent: The scaling between the value shown on the
panel and the integer used in communication when a 32-bit value is
selected for transmission to an external system.
The corresponding 16-bit scalings are listed in chapter Parameters (page
99).
List Selection list.
