ACS550 User’s Manual 19
Installation
• For frame size R6, see section Power terminal considerations – R6 frame size on
page 269 to install the appropriate cable lugs.
• For drives using braking (optional), refer to the following, as appropriate:
• When installing control wiring, refer to the following chapters or sections, as
appropriate:
– Control terminals table on page 22
– Control connections
on page 281
– Application macros on page 71
– Complete parameter descriptions on page 98
– Embedded fieldbus on page 189
– Fieldbus adapter on page 221.
Frame size Terminal Description Braking accessory
R1, R2 BRK+, BRK- Braking resistor Braking resistor. See section Brake
components on page 277.
R3, R4, R5, R6 UDC+, UDC- DC bus Contact your ABB representative to
order either:
• braking unit or
• chopper and resistor
