ACS550 User’s Manual 259
Technical data
Technical data
Ratings
By type code, the table below provides ratings for the ACS550 adjustable speed AC
drive, including:
• IEC ratings
• NEMA ratings (shaded columns)
• frame size.
Ratings, 208…240 V drives
Abbreviated column headers are described in section Symbols on page 261.
Type code Normal use Heavy-duty use
Frame
size
ACS550-x1-
see below
I
2N
A
P
N
kW
P
N
hp
I
2hd
A
P
hd
kW
P
hd
hp
Three-phase supply voltage, 208…240 V
-04A6-2 4.6 0.75 1 3.5 0.55 0.75 R1
-06A6-2 6.6 1.1 1.5 4.6 0.75 1R1
-07A5-2 7.5 1.5 26.61.11.5 R1
-012A-2 11.8 2.2 37.51.52R1
-017A-2 16.7 4 511.82.23R1
-024A-2 24.2 5.5 7.5 16.7 4 5R2
-031A-2 30.8 7.5 10 24.2 5.5 7.5 R2
-046A-2 46.2 11 15 30.8 7.5 10 R3
-059A-2 59.4 15 20 46.2 11 15 R3
-075A-2 74.8 18.5 25 59.4 15 20 R4
-088A-2 88.0 22 30 74.8 18.5 25 R4
-114A-2 114 30 40 88.0 22 30 R4
-143A-2 143 37 50 114 30 40 R6
-178A-2 178 45
60 150 37 50 R6
-221A-2 221 55
75 178 45 60 R6
-248A-2 248 75
100 192 55 75 R6
00467918.xls B
