152 ACS550 User’s Manual
Parameters
Group 36: TIMED FUNCTIONS
This group defines the timed functions. The timed functions include:
• four daily start and stop times
• four weekly start, stop and boost times
• four timers for collecting selected periods together.
A timer can be connected to multiple time periods and a time period can be in
multiple timers.
A parameter can be connected to only one timer.
Time Period 1
3602
START TIME 1
3603
STOP TIME 1
3604
START DAY 1
3605
STOP DAY 1
Time Period 4
3614
START TIME 4
3615
STOP TIME 4
3616
START DAY 4
3617
STOP DAY 4
Time Period 3
3610
START TIME 3
3611
STOP TIME 3
3612
START DAY 3
3613
STOP DAY 3
Time Period 2
3606
START TIME 2
3607
STOP TIME 2
3608
START DAY 2
3609
STOP DAY 2
Booster
3622
BOOSTER SEL
3623 BOOSTER TIME
Timer 1
3626
TIMED FUNC 1 SRC
Timer 2
3627
TIMED FUNC 2 SRC
Timer 3
3628
TIMED FUNC 3 SRC
Timer 4
3629
TIMED FUNC 4 SRC
Timer 2
3627
TIMED FUNC 2 SRC
1001 EXT1 COMMANDS
1002 EXT2 COMMANDS
1102 EXT1/EXT2 SEL
1201 CONST SPEED SEL
1401 RELAY OUTPUT 1…1403 RELAY OUTPUT 3
4027
PID 1 PARAM SET
Timer 1
3626 TIMED FUNC 1 SRC
8126 TIMED AUTOCHNG
1410 RELAY OUTPUT 4…1412 RELAY OUTPUT 6
