290 ACS550 User’s Manual
Technical data
The following table lists the standard stress testing that the ACS550 passes.
Materials
Stress tests
Without shipping package Inside shipping package
Sinusoidal
vibration
Mechanical conditions: In accordance
with IEC 60721-3-3, Class 3M4
• 2…9 Hz 3.0 mm (0.12 in)
• 9…200 Hz 10 m/s
2
(33 ft/s
2
)
In accordance with ISTA 1A and 1B
specifications.
Shock
Not allowed In accordance with IEC 68-2-29:
max. 100 m/s
2
(330 ft/s
2
), 11ms
Free fall
Not allowed • 76 cm (30 in), frame size R1
• 61cm (24 in), frame size R2
• 46 cm (18 in), frame size R3
• 31 cm (12 in), frame size R4
• 25 cm (10 in), frame size R5
• 15 cm (6 in), frame size R6
Material specifications
Drive enclosure
• PC/ABS 2.5 mm, color NCS 1502-Y or NCS 7000-N
• Hot-dip zinc coated steel sheet 1.5…2 mm, thickness of coating 20
micrometers. If the surface is painted, the total thickness of the coating (zinc
and paint) is 80…100 micrometers.
• Cast aluminium AlSi
• Extruded aluminium AlSi
Package
Corrugated board, expanded polystyrene, plywood, raw wood (heat dried).
Package wrap consists of one or more of the following: PE-LD plastic wrap, PP
or steel bands.
Disposal
The drive contains raw materials that should be recycled to preserve energy
and natural resources. The package materials are environmentally compatible
and recyclable. All metal parts can be recycled. The plastic parts can either be
recycled or burned under controlled circumstances, according to local
regulations. Most recyclable parts are marked with recycling marks.
If recycling is not feasible, all parts excluding electrolytic capacitors and printed
circuit boards can be landfilled. The DC capacitors contain electrolyte and, if the
drive is not provided with the RoHS marking, the printed circuit boards contain
lead, both of which will be classified as hazardous waste within the EU. They
must be removed and handled according to local regulations.
For further information on environmental aspects and more detailed recycling
instructions, please contact your local ABB distributor.
