32 ACS550 User’s Manual
Start-up, control with I/O and ID Run
Check that the starting of the motor does not cause any danger.
De-couple the driven machine if:
• there is a risk of damage in case of incorrect direction of rotation, or
• an ID Run needs to be performed during the drive start-up. ID Run is essential only in
applications that require the ultimate in motor control accuracy.
POWER-UP
Apply input power.
The Basic Control Panel powers up into the Output mode.
The Assistant Control Panel asks if you want to run the Start-
up Assistant. If you press , the Start-up Assistant is not
run, and you can continue with manual start-up in a similar
manner as described below for the Basic Control Panel.
MANUAL ENTRY OF START-UP DATA (Group 99: START-UP DATA)
If you have an Assistant Control Panel, select the language
(the Basic Control Panel does not support languages). See
parameter 9901 for the values of the available language
alternatives. You find parameter descriptions in section
Complete parameter descriptions starting on page 98.
The general parameter setting procedure is described below for the Basic
Control Panel. You find more detailed instructions for the Basic Control Panel
on page 67. Instructions for the Assistant Control Panel are on page 49.
The general parameter setting procedure:
1. To go to the Main menu, press if the bottom line shows OUTPUT;
otherwise press repeatedly until you see MENU at the bottom.
2. Press
keys / until you see “PAr” and press .
3. Find the appropriate parameter group with
keys / and press
.
4. Find the appropriate parameter in the group with
keys / .
5. Press and hold for about two seconds until the parameter value is
shown with under the value.
6. Change the value with keys
/. The value changes faster while
you keep the key pressed down.
7. Save the parameter value by pressing .
REM
Hz
OUTPUT FWD
00
.
EXIT
Do you want to
use the start-up
assistant?
Yes
No
EXIT
OK00:00
CHOICE
REM
9901 LANGUAGE
PAR EDIT
ENGLISH
CANCEL SAVE00:00
[0]
REM
REM
MENU FWD
rEF
REM
PAR FWD
-01-
REM
PAR FWD
2001
REM
PAR FWD
2002
SET
REM
rpm
PAR SET FWD
1500
REM
rpm
PAR SET FWD
1600
REM
PAR FWD
2002
