ACS550 User’s Manual 85
Parameters
Parameters
Complete parameter list
The following table lists all parameters. Table header abbreviations are:
•S
= Parameters can be modified only when the drive is stopped.
• User = Space to enter desired parameter values.
Some values depend on the “construction” as indicated in the table by “01:” or “U1:”.
Refer to the type code on the drive, for example ACS550-01..
Code Name Range Resolution Default User S
Group 99: START-UP DATA
9901
LANGUAGE 0…15 / 0…3 1 0 (ENGLISH)
9902
APPLIC MACRO -3…8, 31 1 1 (ABB STANDARD) !
9904
MOTOR CTRL MODE 1=VECTOR:SPEED, 2 = VECTOR:TORQUE,
3=
SCALAR:FREQ
13 (SCALAR:FREQ) !
9905
MOTOR NOM VOLT 115…345 V 1 V 230 V !
01: 200…600 V /
U1: 230…690 V
1 V 01: 400 V /
U1: 460 V
!
U1: 288…862 V 1 V U1: 575 V !
9906 MOTOR NOM CURR 0.2 · I
2hd
… 2.0 · I
2hd
0.1 A 1.0 · I
2hd
!
9907
MOTOR NOM FREQ 10.0.0…500.0 Hz 0.1 Hz 01: 50.0 Hz /
U1: 60.0 Hz
!
9908
MOTOR NOM SPEED 50…30000 rpm 1 rpm Size dependent !
9909
MOTOR NOM POWER 0.2…3.0 · P
hd
01: 0.1 kW /
U1: 0.1 hp
1.0 · P
hd
!
9910
ID RUN 0 = OFF/IDMAGN, 1 = ON 10 (OFF/IDMAGN) !
Group 01: OPERATING DATA
0101
SPEED & DIR -30000…30000 rpm 1 rpm -
0102
SPEED 0…30000 rpm 1 rpm -
0103
OUTPUT FREQ 0.0…500.0 Hz 0.1 Hz -
0104
CURRENT 0.0…2.0 · I
2hd
0.1 A -
0105
TORQUE -200.0…200.0% 0.1% -
0106
POWER -2.0…2.0 · P
hd
0.1 kW -
0107
DC BUS VOLTAGE 0…2.5 · V
dN
1V -
0109
OUTPUT VOLTAGE 0…2.0 · V
dN
1V -
0110
DRIVE TEMP 0.0…150.0 °C0.1°C-
0111
EXTERNAL REF 1 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz -
0112
EXTERNAL REF 2 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0113
CTRL LOCATION 0=LOCAL, 1 = EXT1, 2 = EXT21 -
0114
RUN TIME (R) 0…9999 h 1 h 0 h
0115
KWH COUNTER (R) 0…9999 kWh 1 kWh -
0116
APPL BLK OUTPUT 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0118
DI 1-3 STATUS 000…111 (0…7 decimal) 1 -
