48 ACS550 User’s Manual
Control panels
How to set the speed, frequency or torque reference
How to adjust the display contrast
Step Action Display
1. If you are not in the Output mode, press repeatedly until you get there.
2. If the drive is in remote control (REM shown on the status line), switch to local
control by pressing . The display briefly shows a message about changing
the mode and then returns to the Output mode.
Note: With Group 11: REFERENCE SELECT, you can allow the reference
modification in remote control.
3. • To increase the highlighted reference value shown in the top right corner of the
display, press . The value changes immediately. It is stored in the drive
permanent memory and restored automatically after power switch-off.
• To decrease the value, press .
Step Action Display
1. If you are not in the Output mode, press repeatedly until you get there.
2. • To increase the contrast, press keys and simultaneously.
• To decrease the contrast, press keys and simultaneously.
EXIT
5 A
1 Hz
7 %10.
0.
49.
49.1Hz
REM
DIR
MENU
00:00
LOC
REM
5 A
1 Hz
7 %10.
0.
49.
49.1Hz
LOC
DIR
MENU00:00
5 A
0 Hz
7 %10.
0.
50.
50.0Hz
LOC
DIR
MENU00:00
EXIT
5 A
1 Hz
7 %10.
0.
49.
49.1HzLOC
DIR
MENU00:00
MENU
MENU
5 A
1 Hz
7 %10.
0.
49.
49.1HzLOC
DIR
MENU00:00
