60 ACS550 User’s Manual
Control panels
How to view information about the backup
Step Action Display
1. Go to the Main menu by pressing if you are in the Output mode, otherwise
by pressing repeatedly until you get to the Main menu.
2. Go to the Par Backup mode by selecting PAR BACKUP on the menu with keys
and , and pressing .
3. Select BACKUP INFO on the Copy menu with keys and , and
press . The display shows the following information about the drive where
the backup was made:
DRIVE TYPE: type of the drive
DRIVE RATING: rating of the drive in format XXXYZ, where
XXX: nominal current rating. If present, an “A” indicates
a decimal point, e.g. 4A6 means 4.6 A.
Y: 2 = 200 V
4 = 400 V
6 = 600 V
Z: i = European loading package
n = US loading package
FIRMWARE: firmware version of the drive.
You can scroll the information with keys and .
4. Press to return to the Copy menu.
MENU
EXIT
PARAMETERS
ASSISTANTS
CHANGED PAR
EXIT ENTER00:00
MAIN MENU 1
LOC
ENTER
UPLOAD TO PANEL
BACKUP INFO
DOWNLOAD FULL SET
DOWNLOAD APPLICATION
DOWNLOAD USER SET1
EXIT
SEL00:00
COPY MENU 1
LOC
SEL
EXIT
00:00
DRIVE TYPE
ACS550
3304 DRIVE RATING
4A62i
3301 FIRMWARE
BACKUP INFO
LOC
EXIT
00:00
ACS550
3304 DRIVE RATING
4A62i
3301 FIRMWARE
300F hex
BACKUP INFO
LOC
EXIT
UPLOAD TO PANEL
BACKUP INFO
DOWNLOAD FULL SET
DOWNLOAD APPLICATION
DOWNLOAD USER SET1
EXIT
SEL
00:00
COPY MENU 1
LOC
