86 ACS550 User’s Manual
Parameters
0119 DI 4-6 STATUS 000…111 (0…7 decimal) 1 -
0120
AI 1 0.0…100.0% 0.1% -
0121
AI 2 0.0…100.0% 0.1% -
0122
RO 1-3 STATUS 000…111 (0…7 decimal) 1 -
0123
RO 4-6 STATUS 000…111 (0…7 decimal) 1 -
0124
AO 1 0.0…20.0 mA 0.1 mA -
0125
AO 2 0.0…20.0 mA 0.1 mA -
0126
PID 1 OUTPUT -1000.0…1000.0% 0.1% -
0127
PID 2 OUTPUT -100.0…100.0% 0.1% -
0128
PID 1 SETPNT Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0129
PID 2 SETPNT Unit and scale defined by par. 4206 and
4207
-
0130
PID 1 FBK Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0131
PID 2 FBK Unit and scale defined by par. 4206 and
4207
--
0132
PID 1 DEVIATION Unit and scale defined by par. 4006/
4106 and 4007/4107
--
0133
PID 2 DEVIATION Unit and scale defined by par. 4206 and
4207
--
0134
COMM RO WORD 0…65535 1 0
0135
COMM VALUE 1 -32768…+32767 1 0
0136
COMM VALUE 2 -32768…+32767 1 0
0137
PROCESS VAR 1- 1
0138
PROCESS VAR 2- 1
0139
PROCESS VAR 3- 1
0140
RUN TIME 0.00…499.99 kh 0.01 kh 0.00 kh
0141
MWH COUNTER 0…9999 MWh 1 MWh -
0142
REVOLUTION CNTR 0…65535 Mrev 1 Mrev 0
0143
DRIVE ON TIME HI 0…65535 days 1 day 0
0144
DRIVE ON TIME LO 00:00:00…23:59:58 1 = 2 s 0
0145
MOTOR TEMP Par. 3501 = 1…3: -10…200 °C
Par. 3501 = 4: 0…5000 ohm
Par. 3501 = 5…6: 0…1
1-
0146
MECH ANGLE 0…32768 1 -
0147
MECH REVS -32768 …+32767 1 -
0148
Z PLS DETECTED 0= NOT DETECTED, 1 = DETECTED 1 (DETECTED)-
0150
CB TEMP -20.0…150.0 °C 1.0 °C -
0151
INPUT KWH (R) 0.0…999.9 kWh 1.0 kWh -
0152
INPUT MWH 0…9999 MWh 1 MWh -
0158
PID COMM VALUE 1 -32768 …+32767 1 -
0159
PID COMM VALUE 2 -32768 …+32767 1 -
Group 03: FB ACTUAL SIGNALS
0301
FB CMD WORD 1- - -
0302
FB CMD WORD 2- - -
0303
FB STS WORD 1- - -
Code Name Range Resolution Default User S
