ABB ACS560 - Definitions

Frame
size
Output ratingsMax.
cur-
rent
Nom-
inal
In
Drive
Type
ACS560
Heavy-duty useLight overload
use
Nominal use
P
Hd
I
Hd
(Con-
tinu-
ous)
P
Ld
I
Ld
(Con-
tinu-
ous)
P
N
I
N
I
max
I
1N
HpkWAHpkWAHpkWAAA
R27.55.512.6107.516.2107.51722.717017A-4
R2107.517151123.815112530.625025A-4
R3151124.6201530.420153344.333033A-4
R3201531.62518.536.12518.53956.939039A-4
R32518.537.7302242.830224667.946046A-4
R4302244.64030584030627662062A-4
R4403061503768.450377310473073A-4
R5503772604582.760458812288088A-4
R5604587755599.87555106148106106A-4
R675551051007513810075145178145145A-4
R7100751451209016112090169247169169A-4
R712090169150110196150110206287206206A-4
R8150110206180132234180132246350246246A-4
R8180132
246
1)
215160278215160293418293293A-4
3AXD10000561047.xls A
1)
Continuous current when its used in heavy duty applications, allows 130% of IHd for 1 minute every 10
minutes at 40 °C.
See definitions and notes in section Definitions (page 140).
￭
Definitions
Nominal voltage U
N
Nominal input current (rms) at 40 °C (104 °F) I
1
Maximum output current. Available for two seconds at start. I
max
Nominal output current. Maximum continuous rms output
current allowed (no overload).
I
N
Nominal power of the drive. Typical motor power (no overload-
ing). The kilowatt ratings apply to most IEC 4-pole motors. The
horsepower ratings apply to most NEMA 4-pole motors.
P
N
Maximum current with 110% overload, allowed for one minute
every ten minutes
I
Ld
Typical motor power in light-duty use (110% overload) P
Ld
140 Technical data
