Dimensions
Cabinet line-up dimensions
The drive consists of cubicles built into a cabinet line-up. The tables below show the
composition of cabinet line-ups for each frame size and the standard combinations
of options. The dimensions are in millimeters (for inches, divide by 25.4).
Notes:
• The side panels at the left and right ends of the line-up increase the total line-up
width by 30 millimeters (1.2”).
• The standard depth of the cabinet line-up is 644 mm (25.35”) excluding equipment
such as handles and air inlet gratings. This is increased by 200 mm (7.87”) with
top cable exit units, or by 130 mm with option +C128 (cooling air intake through
bottom of cabinet).
• UL Listed (+C129) units are top cable entry/exit by default.
• Not all possible configurations are presented. For information on unlisted
configurations, contact ABB.
• The data given is preliminary. ABB reserves the right to modify the design at any
time without notice. Consult ABB for up-to-date, drive-specific information.
The tables are followed by selected dimension drawing examples.
13
Dimensions 251
