Parameters 373
49.16 Maximum ext
speed ref panel
Defines a maximum limit for control panel speed reference in
external control.
In local control, the limits in parameter group 30 Limits are in
force. See section Local control vs. external control (page
24).
30000.00
rpm
-30000.00 …
30000.00 rpm
Maximum speed reference. See par.
46.01
49.17 Minimum ext
frequency ref panel
Defines a minimum limit for control panel frequency reference
in external control.
In local control, the limits in parameter group 30 Limits are in
force. See section Local control vs. external control (page
24).
-500.00 Hz
-500.00 … 500.00
Hz
Minimum frequency reference. See par.
46.02
49.18 Maximum ext
frequency ref panel
Defines a maximum limit for control panel frequency
reference in external control.
In local control, the limits in parameter group 30 Limits are in
force. See section Local control vs. external control (page
24).
500.00 Hz
-500.00 … 500.00
Hz
Maximum frequency reference. See par.
46.02
49.24 Panel actual source Selects an actual value to be displayed in the top right corner
of the control panel. This parameter is only effective when the
control panel is not an active reference source.
Automatic
Automatic The active reference is displayed. 0
Process PID
setpoint actual
40.03 Process PID setpoint actual (see page 341). 1
Other Source selection (see Terms and abbreviations on page 148). -
50
50 Fieldbus adapter
(FBA)
Fieldbus communication configuration.
See also chapter Fieldbus control through a fieldbus adapter
(page 631).
50.01 FBA A enable Enables/disables communication between the drive and
fieldbus adapter A, and specifies the slot the adapter is
installed into.
Disable
Disable Communication between drive and fieldbus adapter A
disabled.
0
Option slot 1 Communication between drive and fieldbus adapter A
enabled. The adapter is in slot 1.
1
Option slot 2 Communication between drive and fieldbus adapter A
enabled. The adapter is in slot 2.
2
Option slot 3 Communication between drive and fieldbus adapter A
enabled. The adapter is in slot 3.
3
50.02 FBA A comm loss
func
Selects how the drive reacts upon a fieldbus communication
break. A time delay for the action can be defined by
parameter 50.03 FBA A comm loss t out.
See also parameter 50.26 FBA A comm supervision force.
No action
No action No action taken. 0
No. Name/Value Description Def/FbEq16
