ABB ACS880-104

Additional parameter data 511
Parameter groups 10…99
No. Name Type Range Unit FbEq32
10 Standard DI, RO
10.01 DI status PB 0000h…FFFFh - 1 = 1
10.02 DI delayed status PB 0000h…FFFFh - 1 = 1
10.03 DI force selection PB 0000h…FFFFh - 1 = 1
10.04 DI force data PB 0000h…FFFFh - 1 = 1
10.05 DI1 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.06 DI1 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.07 DI2 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.08 DI2 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.09 DI3 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.10 DI3 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.11 DI4 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.12 DI4 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.13 DI5 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.14 DI5 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.15 DI6 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.16 DI6 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.21 RO status PB 0000h…FFFFh - 1 = 1
10.24 RO1 source Binary
src
--1 = 1
10.25 RO1 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.26 RO1 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.27 RO2 source Binary
src
--1 = 1
10.28 RO2 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.29 RO2 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.30 RO3 source Binary
src
--1 = 1
10.31 RO3 ON delay Real 0.0 … 3000.0 s 10 = 1 s
10.32 RO3 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
10.51 DI filter time Real 0.3 … 100.0 ms 10 = 1 ms
10.99 RO/DIO control word PB 0000h…FFFFh - 1 = 1
11 Standard DIO, FI, FO
11.01 DIO status PB 0000h…FFFFh - 1 = 1
11.02 DIO delayed status PB 0000h…FFFFh - 1 = 1
11.05 DIO1 function List 0…2 - 1 = 1
11.06 DIO1 output source Binary
src
-1 = 1
11.07 DIO1 ON delay Real 0.0 … 3000.0 s 10 = 1 s
11.08 DIO1 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
11.09 DIO2 function List 0…2 - 1 = 1
