ABB ACS880-104

Additional parameter data 559
92.13 Position estimation enable List 0…1 - 1 = 1
92.14 Speed estimation enable List 0…1 - 1 = 1
92.15 Transient filter List 0…3 - 1 = 1
92.16 Encoder 1 supply voltage List 0…2 - 1 = 1
92.17 Accepted pulse freq of
encoder 1
Real 0…300 kHz 1 = 1 kHz
92.21 Encoder cable fault mode List 0…3 - 1 = 1
92.23 Maximum pulse waiting time Real 1…200 ms 1 = 1 ms
92.24 Pulse edge filtering List 0…2 - 1 = 1
92.25 Pulse overfrequency function List 0…1 - 1 = 1
Other parameters in this group when an absolute encoder is selected
92.10 Sine/cosine number Real 0…65535 - 1 = 1
92.11 Absolute position source List 0…5 - 1 = 1
92.12 Zero pulse enable List 0…1 - 1 = 1
92.13 Position data width Real 0…32 - 1 = 1
92.14 Revolution data width Real 0…32 - 1 = 1
92.30 Serial link mode List 0…2 - 1 = 1
92.31 EnDat max calculation time List 0…3 - 1 = 1
92.32 SSI cycle time List 0…5 - 1 = 1
92.33 SSI clock cycles Real 2…127 - 1 = 1
92.34 SSI position msb Real 1…126 - 1 = 1
92.35 SSI revolution msb Real 1…126 - 1 = 1
92.36 SSI data format List 0…1 - 1 = 1
92.37 SSI baud rate List 0…5 - 1 = 1
92.40 SSI zero phase List 0…3 - 1 = 1
92.45 Hiperface parity List 0…1 - 1 = 1
92.46 Hiperface baud rate List 0…3 - 1 = 1
92.47 Hiperface node address Real 0…255 - 1 = 1
Other parameters in this group when a resolver is selected
92.10 Excitation signal frequency Real 1…20 kHz 1 = 1 kHz
92.11 Excitation signal amplitude Real 4.0 … 12.0 V 10 = 1 V
92.12 Resolver polepairs List 1…32 - 1 = 1
93 Encoder 2 configuration
93.01 Encoder 2 type List 0…7 - 1 = 1
93.02 Encoder 2 source List 1…2 - 1 = 1
Other parameters in this group when a TTL, TTL+ and HTL encoder is selected
(93.16, 93.17, 93.23…93.25 visible depending on encoder type selection)
93.10 Pulses/rev Real 0…65535 - 1 = 1
93.11 Pulse encoder type List 0…1 - 1 = 1
93.12 Speed calculation mode List 0…5 - 1 = 1
93.13 Position estimation enable List 0…1 - 1 = 1
93.14 Speed estimation enable List 0…1 - 1 = 1
No. Name Type Range Unit FbEq32
