ABB ACS880-104

558 Additional parameter data
90.64 Feed constant denominator Real -2147483648 …
2147483647
-1 = 1
90.65 Pos counter init value Real -2147483.648 …
2147483.647
-1 = 1
90.66 Pos counter init value source Binary
src
--1 = 1
90.67 Pos counter init cmd source Binary
src
--1 = 1
90.68 Disable pos counter
initialization
Binary
src
--1 = 1
90.69 Reset pos counter init ready Binary
src
--1 = 1
91 Encoder module settings
91.01 FEN DI status PB 000000b…111111b - 1 = 1
91.02 Module 1 status List --1 = 1
91.03 Module 2 status List --1 = 1
91.04 Module 1 temperature Real 0…1000 °C, °F or
ohm
1 = 1 unit
91.06 Module 2 temperature Real 0…1000 °C, °F or
ohm
1 = 1 unit
91.10 Encoder parameter refresh List 0…1 - 1 = 1
91.11 Module 1 type List 0…4 - 1 = 1
91.12 Module 1 location Real 1…254 - 1 = 1
91.13 Module 2 type List 0…4 - 1 = 1
91.14 Module 2 location Real 1…254 - 1 = 1
91.21 Module 1 temp sensor type List 0…2 - 1 = 1
91.22 Module 1 temp filter time Real 0…10000 ms 1 = 1 ms
91.24 Module 2 temp sensor type List 0…2 - 1 = 1
91.25 Module 2 temp filter time Real 0…10000 ms 1 = 1 ms
91.31 Module 1 TTL output source List 0…2 - 1 = 1
91.32 Module 1 emulation pulses/rev Real 0…65535 - 1 = 1
91.33 Module 1 emulated Z-pulse
offset
Real 0.00000 … 1.00000 rev 100000 = 1 rev
91.41 Module 2 TTL output source List 0…2 - 1 = 1
91.42 Module 2 emulation pulses/rev Real 0…65535 - 1 = 1
91.43 Module 2 emulated Z-pulse
offset
Real 0.00000 … 1.00000 rev 100000 = 1 rev
92 Encoder 1 configuration
92.01 Encoder 1 type List 0…7 - 1 = 1
92.02 Encoder 1 source List 1…2 - 1 = 1
Other parameters in this group when a TTL, TTL+ and HTL encoder is selected
(92.16, 92.17, 92.23…92.25 visible depending on encoder type selection)
92.10 Pulses/revolution Real 0…65535 - 1 = 1
92.11 Pulse encoder type List 0…1 - 1 = 1
92.12 Speed calculation mode List 0…5 - 1 = 1
No. Name Type Range Unit FbEq32
