ABB ACS880-104

534 Additional parameter data
36.42 AL2 20 to 30% Real 0.00 … 100.00 % 100 = 1%
36.43 AL2 30 to 40% Real 0.00 … 100.00 % 100 = 1%
36.44 AL2 40 to 50% Real 0.00 … 100.00 % 100 = 1%
36.45 AL2 50 to 60% Real 0.00 … 100.00 % 100 = 1%
36.46 AL2 60 to 70% Real 0.00 … 100.00 % 100 = 1%
36.47 AL2 70 to 80% Real 0.00 … 100.00 % 100 = 1%
36.48 AL2 80 to 90% Real 0.00 … 100.00 % 100 = 1%
36.49 AL2 over 90% Real 0.00 … 100.00 % 100 = 1%
36.50 AL2 reset date Data --1 = 1
36.51 AL2 reset time Data --1 = 1
37 User load curve
37.01 ULC output status word PB 0000h…FFFFh - 1 = 1
37.02 ULC supervision signal List --1 = 1
37.03 ULC overload actions List 0…3 - 1 = 1
37.04 ULC underload actions List 0…3 - 1 = 1
37.11 ULC speed table point 1 Real 0.0 … 30000.0 rpm 10 = 1 rpm
37.12 ULC speed table point 2 Real 0.0 … 30000.0 rpm 10 = 1 rpm
37.13 ULC speed table point 3 Real 0.0 … 30000.0 rpm 10 = 1 rpm
37.14 ULC speed table point 4 Real 0.0 … 30000.0 rpm 10 = 1 rpm
37.15 ULC speed table point 5 Real 0.0 … 30000.0 rpm 10 = 1 rpm
37.16 ULC frequency table point 1 Real 0.0 … 500.0 Hz 10 = 1 Hz
37.17 ULC frequency table point 2 Real 0.0 … 500.0 Hz 10 = 1 Hz
37.18 ULC frequency table point 3 Real 0.0 … 500.0 Hz 10 = 1 Hz
37.19 ULC frequency table point 4 Real 0.0 … 500.0 Hz 10 = 1 Hz
37.20 ULC frequency table point 5 Real 0.0 … 500.0 Hz 10 = 1 Hz
37.21 ULC underload point 1 Real 0.0 … 1600.0 % 10 = 1%
37.22 ULC underload point 2 Real 0.0 … 1600.0 % 10 = 1%
37.23 ULC underload point 3 Real 0.0 … 1600.0 % 10 = 1%
37.24 ULC underload point 4 Real 0.0 … 1600.0 % 10 = 1%
37.25 ULC underload point 5 Real 0.0 … 1600.0 % 10 = 1%
37.31 ULC overload point 1 Real 0.0 … 1600.0 % 10 = 1%
37.32 ULC overload point 2 Real 0.0 … 1600.0 % 10 = 1%
37.33 ULC overload point 3 Real 0.0 … 1600.0 % 10 = 1%
37.34 ULC overload point 4 Real 0.0 … 1600.0 % 10 = 1%
37.35 ULC overload point 5 Real 0.0 … 1600.0 % 10 = 1%
37.41 ULC overload timer Real 0.0 … 10000.0 s 10 = 1 s
37.42 ULC underload timer Real 0.0 … 10000.0 s 10 = 1 s
40 Process PID set 1
40.01 Process PID output actual Real -32768.00 … 32767.00 rpm, % or
Hz
100 = 1 rpm, %
or Hz
40.02 Process PID feedback actual Real -32768.00 … 32767.00 rpm, % or
Hz
100 = 1 rpm, %
or Hz
No. Name Type Range Unit FbEq32
