156 Parameters
01.114 Grid reactive power (Only visible when IGBT supply unit control activated by
95.20)
Estimated reactive power being transferred through the
supply unit.
-
-30000.00 …
30000.00 kvar
Estimated reactive power. 10 = 1 kvar
01.116 LSU cos Φ (Only visible when IGBT supply unit control activated by
95.20)
Power factor of the supply unit.
-
-1.00 … 1.00 Power factor. 100 = 1
01.164 LSU nominal power (Only visible when IGBT supply unit control activated by
95.20)
Nominal power of the supply unit.
-
0…30000 kW Nominal power. 1 = 1 kW
03
03 Input references
Values of references received from various sources.
All parameters in this group are read-only unless otherwise
noted.
03.01 Panel reference Local reference given from the control panel or PC tool. -
-100000.00 …
100000.00
Local control panel or PC tool reference. 1 = 10
03.02 Panel reference 2 Remote reference given from the control panel or PC tool. -
-30000.00 …
30000.00
Remote control panel or PC tool reference. 1 = 10
03.05 FB A reference 1 Reference 1 received through fieldbus adapter A.
See also chapter Fieldbus control through a fieldbus adapter
(page 631).
-
-100000.00 …
100000.00
Reference 1 from fieldbus adapter A. 1 = 10
03.06 FB A reference 2 Reference 2 received through fieldbus adapter A. -
-100000.00 …
100000.00
Reference 2 from fieldbus adapter A. 1 = 10
03.07 FB B reference 1 Reference 1 received through fieldbus adapter B. -
-100000.00 …
100000.00
Reference 1 from fieldbus adapter B. 1 = 10
03.08 FB B reference 2 Reference 2 received through fieldbus adapter B. -
-100000.00 …
100000.00
Reference 2 from fieldbus adapter B. 1 = 10
03.09 EFB reference 1 Scaled reference 1 received through the embedded fieldbus
interface. The scaling is defined by 58.26 EFB ref1 type.
1 = 10
-30000.00 …
30000.00
Reference 1 received through the embedded fieldbus
interface.
1 = 10
03.10 EFB reference 2 Scaled reference 2 received through the embedded fieldbus
interface. The scaling is defined by 58.27 EFB ref2 type.
1 = 10
-30000.00 …
30000.00
Reference 2 received through the embedded fieldbus
interface.
1 = 10
No. Name/Value Description Def/FbEq16
