ABB ACS880-104

302 Parameters
30.104 LSU limit word 4 (Only visible when IGBT supply unit control activated by
95.20)
Displays limit word 4 of the supply unit.
This parameter is read-only.
-
0000h…FFFFh Supply unit limit word 4. 1 = 1
30.148 LSU minimum
power limit
(Only visible when IGBT supply unit control activated by
95.20)
Defines a minimum power limit for the supply unit.
Negative values refer to regenerating, ie. feeding power into
the supply network.
-130.0%
-200.0 … 0.0% Minimum power limit for supply unit. 1 = 1%
30.149 LSU maximum
power limit
(Only visible when IGBT supply unit control activated by
95.20)
Defines a maximum power limit for the supply unit.
130.0%
0.0 … 200.0% Maximum power limit for supply unit. 1 = 1%
31
31 Fault functions
Configuration of external events; selection of behavior of the
drive upon fault situations.
31.01 External event 1
source
Defines the source of external event 1.
See also parameter 31.02 External event 1 type.
0 = Trigger event
1 = Normal operation
Inactive
(true); DI6
(95.20 b8)
Active (false) 0. 0
Inactive (true) 1. 1
DIIL DIIL input (10.02 DI delayed status, bit 15). 2
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 3
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 4
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 5
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 6
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 7
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 8
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 11
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 12
Other [bit] Source selection (see Terms and abbreviations on page 148). -
31.02 External event 1
type
Selects the type of external event 1. Fault
(95.20 b8)
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Udc ref max 1 = DC reference is being limited by supply control program
parameters
1 Udc ref min
2 User I max 1 = Current is being limited by supply control program parameters
3 Temp I max 1 = Current is being limited based on temperature
4…15 Reserved
