ABB ACS880-104

560 Additional parameter data
93.15 Transient filter List 0…3 - 1 = 1
93.16 Encoder 2 supply voltage List 0…2 - 1 = 1
93.17 Accepted pulse freq of
encoder 2
Real 0…300 kHz 1 = 1 kHz
93.21 Encoder cable fault mode List 0…3 - 1 = 1
93.23 Maximum pulse waiting time Real 1…200 ms 1 = 1 ms
93.24 Pulse edge filtering List 0…2 - 1 = 1
93.25 Pulse overfrequency function List 0…1 - 1 = 1
Other parameters in this group when an absolute encoder is selected
93.10 Sine/cosine number Real 0…65535 - 1 = 1
93.11 Absolute position source List 0…5 - 1 = 1
93.12 Zero pulse enable List 0…1 - 1 = 1
93.13 Position data width Real 0…32 - 1 = 1
93.14 Revolution data width Real 0…32 - 1 = 1
93.30 Serial link mode List 0…2 - 1 = 1
93.31 EnDat calc time List 0…3 - 1 = 1
93.32 SSI cycle time List 0…5 - 1 = 1
93.33 SSI clock cycles Real 2…127 - 1 = 1
93.34 SSI position msb Real 1…126 - 1 = 1
93.35 SSI revolution msb Real 1…126 - 1 = 1
93.36 SSI data format List 0…1 - 1 = 1
93.37 SSI baud rate List 0…5 - 1 = 1
93.40 SSI zero phase List 0…3 - 1 = 1
93.45 Hiperface parity List 0…1 - 1 = 1
93.46 Hiperface baud rate List 0…3 - 1 = 1
93.47 Hiperface node address Real 0…255 - 1 = 1
Other parameters in this group when a resolver is selected
93.10 Excitation signal frequency Real 1…20 kHz 1 = 1 kHz
93.11 Excitation signal amplitude Real 4.0 … 12.0 V 10 = 1 V
93.12 Resolver polepairs List 1…32 - 1 = 1
94 LSU control
(Group only visible when supply unit control activated by 95.20)
94.01 LSU control List 0…1 - 1 = 1
94.02 LSU panel communication List 0…1 - 1 = 1
94.10 LSU max charging time Real 0…65535 s 1 = 1 s
94.11 LSU stop delay Real 0.0 … 3600.0 s 10 = 1 s
(Parameters 94.20…94.32 only visible when IGBT supply unit control activated by 95.20)
94.20 DC voltage reference Real 0.0 … 2000.0 V 10 = 1 V
94.21 DC voltage ref source List --1 = 1
94.22 User DC voltage reference Real 0.0 … 2000.0 V 10 = 1 V
94.30 Reactive power reference Real -3276.8 … 3276.7 kvar 10 = 1 kvar
No. Name Type Range Unit FbEq32
