ABB ACS880-104

Additional parameter data 505
Parameter groups 1…9
No. Name Type Range Unit FbEq32
01 Actual values
01.01 Motor speed used Real -30000.00 … 30000.00 rpm 100 = 1 rpm
01.02 Motor speed estimated Real -30000.00 … 30000.00 rpm 100 = 1 rpm
01.03 Motor speed % Real -1000.00 … 1000.00 % 100 = 1%
01.04 Encoder 1 speed filtered Real -30000.00 … 30000.00 rpm 100 = 1 rpm
01.05 Encoder 2 speed filtered Real -30000.00 … 30000.00 rpm 100 = 1 rpm
01.06 Output frequency Real -500.00 … 500.00 Hz 100 = 1 Hz
01.07 Motor current Real 0.00 … 30000.00 A 100 = 1 A
01.08 Motor current % of motor nom Real 0.0 … 1000.0 % 10 = 1%
01.10 Motor torque Real -1600.0 … 1600.0 % 10 = 1%
01.11 DC voltage Real 0.00 … 2000.00 V 100 = 1 V
01.13 Output voltage Real 0…2000 V 1 = 1 V
01.14 Output power Real -32768.00 … 32767.00 kW or hp 100 = 1 unit
01.15 Output power % of motor nom Real -300.00 … 300.00 % 10 = 1%
01.17 Motor shaft power Real -32768.00 … 32767.00 kW or hp 100 = 1 unit
01.18 Inverter GWh motoring Real 0…32767 GWh 1 = 1 GWh
01.19 Inverter MWh motoring Real 0…999 MWh 1 = 1 MWh
01.20 Inverter kWh motoring Real 0…999 kWh 1 = 1 kWh
01.21 U-phase current Real -30000.00 … 30000.00 A 100 = 1 A
01.22 V-phase current Real -30000.00 … 30000.00 A 100 = 1 A
01.23 W-phase current Real -30000.00 … 30000.00 A 100 = 1 A
01.24 Flux actual % Real 0…200 % 1 = 1%
01.29 Speed change rate Real -15000 … 15000 rpm/s 1 = 1 rpm/s
01.30 Nominal torque scale Real 0.000… N·m or
lb·ft
1000 = 1 unit
01.31 Ambient temperature Real -40 … 120 °C or °F 10 = 1°
01.32 Inverter GWh regenerating Real 0…32767 GWh 1 = 1 GWh
01.33 Inverter MWh regenerating Real 0…999 MWh 1 = 1 MWh
01.34 Inverter kWh regenerating Real 0…999 kWh 1 = 1 kWh
01.35 Mot - regen energy GWh Real -32768 … 32767 GWh 1 = 1 GWh
01.36 Mot - regen energy MWh Real -999…999 MWh 1 = 1 MWh
01.37 Mot - regen energy kWh Real -999…999 kWh 1 = 1 kWh
01.61 Abs motor speed used Real 0.00 … 30000.00 rpm 100 = 1 rpm
01.62 Abs motor speed% Real 0.00 … 1000.00 % 100 = 1%
01.63 Abs output frequency Real
0.00 … 500.00 Hz 100 = 1 Hz
01.64 Abs motor torque Real 0.0 … 1600.0 % 10 = 1%
01.65 Abs output power Real 0.00 … 32767.00 kW or hp 100 = 1 unit
01.66 Abs output power % motor
nom
Real 0.00 … 300.00 % 10 = 1%
01.68 Abs motor shaft power Real 0.00 … 32767.00 kW or hp 100 = 1 unit
