382 Parameters
51.30 FBA A mapping file
ver
Displays the fieldbus adapter module mapping file revision
stored in the memory of the drive in decimal format.
This parameter is read-only.
-
0…65535 Mapping file revision. 1 = 1
51.31 D2FBA A comm
status
Displays the status of the fieldbus adapter module
communication.
-
Not configured Adapter is not configured. 0
Initializing Adapter is initializing. 1
Time out A timeout has occurred in the communication between the
adapter and the drive.
2
Configuration error Adapter configuration error: mapping file not found in the file
system of the drive, or mapping file upload has failed more
than three times.
3
Off-line Fieldbus communication is off-line. 4
On-line Fieldbus communication is on-line, or fieldbus adapter has
been configured not to detect a communication break. For
more information, see the documentation of the fieldbus
adapter.
5
Reset Adapter is performing a hardware reset. 6
51.32 FBA A comm SW
ver
Displays the patch and build versions of the adapter module
firmware in format xxyy, where xx = patch version number, yy
= build version number.
Example: C802 = 200.02 (patch version 200, build version 2).
Patch and build versions of adapter module firmware. -
51.33 FBA A appl SW ver Displays the major and minor versions of the adapter module
firmware in format xyy, where x = major revision number, yy =
minor revision number.
Example: 300 = 3.00 (major version 3, minor version 00).
Major and minor versions of adapter module firmware. -
52
52 FBA A data in
Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter, the
next parameter is automatically reserved.
52.01 FBA A data in1 Parameters 52.01…52.12 select data to be transferred from
the drive to the fieldbus controller through fieldbus adapter A.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits) 5
Act2 16bit Actual value ACT2 (16 bits) 6
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
SW 32bit Status Word (32 bits) 14
No. Name/Value Description Def/FbEq16
